Description
V-SUM-RB-F
The thoughtful ergonomics and supportive positioning of our Summit Recumbent Bike offer a comfortable, accessible ride anyone can enjoy. Easy entry and intuitive controls encourage confidence, while durable, commercial-grade components ensure reliable performance and simplified service in high-traffic facilities.
PRODUCT FEATURES
Lasting Comfort
A supportive seat promotes proper alignment for smooth, natural, low-impact rides. Thoughtful ergonomics help users stay comfortable from the moment they sit down to the end of their longest ride yet.
Built Strong
The reinforced crank assembly is engineered to withstand the demands of heavy commercial use. Robust construction delivers dependable performance day after day, giving facility owners durability they can count on for years.
Easy Entry
A step-through frame makes getting on and off the bike simple for users of all abilities. The open design creates a more accessible, welcoming experience while inspiring confidence in every workout.
Space Efficiency
A footprint 10% smaller than competitive designs maximizes your cardio floor without sacrificing performance. Fit more equipment into your space while creating a comfortable, inviting environment for users.
PRODUCT FEATURES
Frame Type
Heavy-gauge welded steel
Stride Length
51.3 cm / 20"
Step-on Height
24 cm / 9.5"
Power Incline
No
Resistance System
Two-stage, self-powered generator
Resistance Range
1–30
Pedal Type
Oversized with rubber inserts and front guard
Pedal Spacing
5.9 cm / 2.3"
Handlebar Design
Dual action and stationary with heart rate grips
Assembled Dimensions
147 × 78 × 167 cm / 58" × 30.7" × 65.7"
Assembled Weight
150 kg / 330 lbs.
Max User Weight
182 kg / 400 lbs.
Power Requirements
Self-powered or 100–240 V — 50/60 Hz AC (may vary by region)
DLED Specifications
Display Type
41 cm / 16" class capacitive touchscreen LCD
Workout Programs
Go, manual, Sprint 8, Virtual Active, target heart rate, fat burn, rolling hills, time goal, distance goal, calorie goal, 6 fitness tests, custom, HIIT mode, landmarks
Workout Feedback
Time, pace, incline, distance, speed, level, calories, METs, target HR, actual HR, profile
Heart Rate
Contact, telemetric, Bluetooth
WiFi
Optional: for connection to Vision Asset Management
Bluetooth
Yes: connection to Vision Fitness app, heart rate device or FTMS-enabled fitness app
USB Port
Yes: USB-A for device charging and software updates
HDMI IN Port
Screen cast of smart devices which support HDMI out to console
QR Code
Yes: connects to console demonstration video and Vision Fitness app download link
Power Consumption (standby)
Less than 0.5W
Power Consumption (off)
Less than 0.3W
